ACT512 Panasonic - Power Relay - ManyChip Electronics

Image is for your reference only,please check specifications for details

ACT512 - Panasonic
Manufacturer:
Panasonic
ManyChip's Part#:
MC11405735
Category:
Power Relay
Datasheet:
Datasheet 3D Model
Description:
Силовое/сигнальное реле, SPDT, однократное срабатывание, 0.067 А (катушка), 12 В пост. тока (катушка), 800 мВт (катушка), 10 А (контакт), 14 В пост. тока (контакт), вход пост. тока, выход пост. тока, монтаж в отверстие, вертикальный, соответствует ROHS
Stock Locations:
Availability:
71 pcs In Stock
MOQ:
1 pcs
Unit Price:
$ 0.89

Updated at 16/09/2026 10:30:15(UTC+8)

Certifications

ManyChip is committed to product quality and safety with ISO 9001, ISO 13485, ISO 45001, UL, RoHS, CQC and REACH certifications.

Description

Реле ACT512 — это однополюсное сверхминиатюрное сдвоенное автомобильное реле серии CT. Конфигурация контактов: 1 переключающий (Form-C), контакты из серебряного сплава (без кадмия). Сдвоенный тип с 10 выводами. Возможно управление прямым/реверсивным вращением двигателя с помощью одного реле. Простая компоновка выводов облегчает проектирование печатной платы.
Диапазон рабочих температур: от -40 до 85 °C.

Show

Attribute	Attribute Value

Datasheet	Datasheet
3D Model	3D Model
Mounting Style	Through Hole
Number of Pins	10 Pin
Voltage Rating (DC)	14 V
Contacts Type	SPDT
Power Consumption	800 mW
Contact Current Rating	20 A
Coil Voltage	12 VDC
Coil Current	66.7 mA
Coil Resistance	180 Ω
Coil Voltage (DC)	12 V
Coil Power	800 mW
Operating Temperature (Max)	85 ℃
Operating Temperature (Min)	-40 ℃
	Show
Size-Length	17.4 mm
Size-Width	14 mm
Size-Height	13.5 mm
Contact Material	Silver Alloy
Operating Temperature	-40℃ ~ 85℃
Product Lifecycle Status	Active
Packaging	Tube
RoHS	RoHS Compliant
Lead-Free Status	Lead Free
REACH SVHC Compliance	No SVHC
REACH SVHC Compliance Edition	2015/06/15
HTS Code	8536410050
ECCN Code	EAR99
