Attribute | Attribute Value |
---|---|
Datasheet | Datasheet |
3D Model | 3D Model |
Mounting Style | Surface Mount |
Number of Pins | 20 Pin |
Case/Package | TSSOP-20 |
Supply Voltage (DC) | 2.00V ~ 3.60V |
Number of Outputs | 8 Output |
Output Current | 24.0 mA |
Number of Channels | 8 Channel |
Number of Positions | 20 Position |
Number of Bits | 8 Bit |
Propagation Delay Max (tpd) | 5.10 ns |
Voltage Nodes | 3.30 V, 2.70 V, 2.50 V, 1.80 V |
Output Current Drive | -1.00 mA |
Number of Inputs | 8 Input |
Operating Temperature (Max) | 85 ℃ |
Operating Temperature (Min) | -40 ℃ |
Supply Voltage | 1.65V ~ 3.6V |
Supply Voltage (Max) | 3.6 V |
Supply Voltage (Min) | 1.65 V |
Show | |
Size-Length | 6.5 mm |
Size-Width | 4.5 mm |
Size-Height | 1.05 mm |
Operating Temperature | -40℃ ~ 85℃ |
Product Lifecycle Status | Active |
Packaging | Tape & Reel (TR) |
RoHS | RoHS Compliant |
Lead-Free Status | Lead Free |
REACH SVHC Compliance | No SVHC |
REACH SVHC Compliance Edition | 2015/06/15 |
ECCN Code | EAR99 |
