Description
- With the implementation of this high side VNQ860 power switch by STMicroelectronics you can expect to safely switch between various voltage and current levels in your electrical circuit. This charge controller has 4 outputs. This device has a maximum power dissipation of 16000 mW. It features 0.27(Max) Ohm switch on resistance. Its maximum power dissipation is 16000 mW. This device has a supply current of 0.12(Max) mA and a minimum output current of 0.35(Max) A. In order to ensure parts aren"t damaged by bulk packaging, this product comes in tube packaging to add a little more protection by storing the loose parts in an outer tube. This charge controller has an operating temperature range of -40 °C to 150 °C.
VNQ860 Specifications
| Attribute | Attribute Value |
|---|---|
| Datasheet | Datasheet |
| 3D Model | 3D Model |
| Mounting Style | Surface Mount |
| Number of Pins | 20 Pin |
| Case/Package | SOIC-20 |
| Supply Voltage (DC) | 36.0V (max) |
| Voltage Rating (DC) | 36.0 V |
| Number of Outputs | 4 Output |
| Supply Current | 120 mA |
| Number of Channels | 4 Channel |
| Drain to Source Resistance (on) (Rds) | 540 mΩ |
| Power Dissipation | 16000 mW |
| Output Current (Max) | 250 mA |
| Operating Temperature (Max) | 150 ℃ |
| Operating Temperature (Min) | -55 ℃ |
| Supply Voltage | 5.5V ~ 36V |
| Show | |
| Operating Temperature | -40℃ ~ 150℃ (TJ) |
| Product Lifecycle Status | Unknown |
| Packaging | Tube |
| RoHS | RoHS Compliant |
| Lead-Free Status | Lead Free |
| ECCN Code | EAR99 |
