Attribute | Attribute Value |
---|---|
Datasheet | Datasheet |
3D Model | 3D Model |
Mounting Style | Surface Mount |
Number of Pins | 8 Pin |
Case/Package | SOIC-8 |
Output Voltage | 70.0 V |
Number of Channels | 2 Channel |
Number of Positions | 8 Position |
Forward Voltage | 1.55 V |
Input Current | 30 mA |
Power Dissipation | 0.3 W |
Rise Time | 5 µs |
Isolation Voltage | 4000 v |
Forward Current | 30 mA |
Input Current (Min) | 30 mA |
Reverse Breakdown Voltage | 6 V |
Maximum Forward Voltage (Max) | 1.55 V |
Forward Current (Max) | 30 mA |
Fall Time | 4 µs |
Operating Temperature (Max) | 100 ℃ |
Operating Temperature (Min) | -40 ℃ |
Power Dissipation (Max) | 300 mW |
Show | |
Operating Temperature | -40℃ ~ 100℃ |
Product Lifecycle Status | Not Recommended for New Design |
Packaging | Tape & Reel (TR) |
RoHS | RoHS Compliant |
Lead-Free Status | Lead Free |
ECCN Code | EAR99 |
