Attribute | Attribute Value |
---|---|
Datasheet | Datasheet |
3D Model | 3D Model |
Mounting Style | Surface Mount |
Case/Package (SI) | 4532 |
Case/Package | 1812 |
Time to Trip | 150 ms |
Power Dissipation | 0.8 W |
Resistance | 1 Ω |
Holding Current | 500 mA |
Trip Current | 1 A |
Current Rating (Max) | 100 A |
Holding Current (Max) | 500 mA |
Operating Temperature (Max) | 85 ℃ |
Operating Temperature (Min) | -40 ℃ |
Voltage Rating (Max) | 30 VDC |
Voltage Rating | 30 VDC |
Show | |
Size-Length | 4.5500 mm |
Size-Width | 3.2400 mm |
Size-Height | 1.0500 mm |
Operating Temperature | -40℃ ~ 85℃ |
Product Lifecycle Status | Active |
Packaging | Tape & Reel (TR) |
RoHS | RoHS Compliant |
Lead-Free Status | Lead Free |
ECCN Code | EAR99 |
