Image is for your reference only,please check specifications for details
- 150066SV74000 - Wurth Electronics
-
Manufacturer:Wurth Electronics
-
ManyChip's Part#:MC15992359
-
Category:Based LED
-
Package:0606
-
Datasheet:Datasheet 3D Model
-
Description:Светодиод, красный, зеленый, R 55 мкд, G 30 мкд, 130°, R 2 В, G 2 В, R 20 мА, G 20 мА
-
Stock Locations:
-
Availability:0 pcs In Stock
-
MOQ:1 pcs
-
Unit Price:$ 0
Updated at 16/09/2026 10:30:15(UTC+8)
Certifications
ManyChip is committed to product quality and safety with ISO 9001, ISO 13485, ISO 45001, UL, RoHS, CQC and REACH certifications.
Description
- Светодиод 150066SV74000 является поверхностно-монтируемым сверхярким красным и ярко-зеленым чип-светодиодом на технологии AllnGaP и совместим с автоматами для установки компонентов. Светодиоды серии WL-SBCW отличаются высокой эффективностью и низким энергопотреблением.
- Малый размер
- Стандартное промышленное посадочное место
- Широкий угол обзора
150066SV74000 Specifications
| Attribute | Attribute Value |
|---|---|
| Datasheet | Datasheet |
| 3D Model | 3D Model |
| Mounting Style | Surface Mount |
| Number of Pins | 4 Pin |
| Case/Package | 0606 |
| Forward Voltage | 2 V |
| Wavelength | 630nm Red, 570nm Green |
| Viewing Angle | 130° |
| Peak Wavelength | 572nm Green,645nm Red |
| Power Dissipation | 72 W |
| Test Current | 20 mA |
| Forward Current | 30 mA |
| Operating Temperature (Max) | 85 ℃ |
| Operating Temperature (Min) | -40 ℃ |
| Show | |
| Size-Length | 1.6 mm |
| Size-Width | 1.6 mm |
| Size-Height | 0.7 mm |
| Color | Red, Yellow |
| Product Lifecycle Status | Active |
| Packaging | Cut Tape (CT) |
| RoHS | RoHS Compliant |
| Lead-Free Status | Lead Free |
| REACH SVHC Compliance | No SVHC |
