Image is for your reference only,please check specifications for details
Updated at 01/11/2025 10:30:15(UTC+8)
Certifications
ManyChip is committed to product quality and safety with ISO 9001, ISO 13485, ISO 45001, UL, RoHS, CQC and REACH certifications.
Description
- Conn Terminal Block 2 POS 5mm Solder RA SMD 13.5A
1824747 Specifications
| Attribute | Attribute Value |
|---|---|
| Datasheet | Datasheet |
| 3D Model | 3D Model |
| Mounting Style | Surface Mount |
| Case/Package | - |
| Number of Contacts | 2 Contact |
| Wire Gauge | 16AWG ~ 24AWG |
| Number of Rows | 1 Row |
| Number of Circuits | 2 Circuit |
| Current Rating (Max) | 13.5 A |
| Operating Temperature (Min) | -40 ℃ |
| Voltage Rating (Max) | 320 V |
| Voltage Rating | 500 V |
| Operating Voltage (Max) | 320 V |
| Show | |
| Size-Length | 9 mm |
| Size-Width | 7.7 mm |
| Size-Height | 7.7 mm |
| Housing Color | Black |
| Color | Black |
| Contact Material | Copper Alloy |
| Product Lifecycle Status | Active |
| Packaging | Tape |
| RoHS | RoHS Compliant |
| Lead-Free Status | Lead Free |
