Description
- The 1SMB5919BT3G is a surface mount Zener Voltage Regulator Diode with void-free transfer-moulded thermosetting plastic case, all external surfaces are corrosion-resistant and leads are readily solderable finish and cathode indicated by polarity. This Zener diode is designed for general purpose voltage regulation applications.
- Flat handling surface for accurate placement
- 5µA at 3V Leakage current
- 367mA Maximum DC Zener current
- ESD sensitive device, take proper precaution while handling the device.
1SMB5919BT3G Specifications
| Attribute | Attribute Value |
|---|---|
| Datasheet | Datasheet |
| 3D Model | 3D Model |
| Mounting Style | Surface Mount |
| Number of Pins | 2 Pin |
| Case/Package | SMB |
| Voltage Rating (DC) | 5.60 V |
| Capacitance Tolerance | ±5 % |
| Power Rating | 3.00 W |
| Halogen Free Status | Halogen Free |
| Breakdown Voltage | 5.88 V |
| Number of Positions | 2 Position |
| Forward Voltage | 1.5 V |
| Power Dissipation | 3 W |
| Test Current | 66.9 mA |
| Forward Current | 200 mA |
| Zener Voltage | 5.6 V |
| Maximum Forward Voltage (Max) | 1.5V @200mA |
| Input Power (Max) | 3 W |
| Operating Temperature (Max) | 150 ℃ |
| Operating Temperature (Min) | -65 ℃ |
| Junction Temperature (Max) | 150 ℃ |
| Power Dissipation (Max) | 550 mW |
| Show | |
| Size-Length | 4.32 mm |
| Size-Width | 3.56 mm |
| Size-Height | 2.13 mm |
| Material | Plastic |
| Operating Temperature | -65℃ ~ 150℃ |
| Product Lifecycle Status | Active |
| Packaging | Tape & Reel (TR) |
| RoHS | RoHS Compliant |
| Lead-Free Status | Lead Free |
| REACH SVHC Compliance | No SVHC |
| ECCN Code | EAR99 |
