Image is for your reference only,please check specifications for details
Updated at 17/06/2025 10:30:15(UTC+8)
Certifications
ManyChip is committed to product quality and safety with ISO 9001, ISO 13485, ISO 45001, UL, RoHS, CQC and REACH certifications.
Description
- The 2940207 is a Solid State Relay Terminal Block with zero voltage switching mode and screw terminals. This DIN-rail-mount terminal block features EB-DIK insertion bridges, protection against polarity reversal and free-wheeling diode, integrated output protective circuit and input circuit. Labelling and mounting with user-friendly modular terminal blocks.
- Actuator version
- Wear-free switching
- Green LED status indicator
- 2.5mm² Maximum conductor cross section
- * 10mW Power dissipation
- 20µs Response and 200µs turn-off typical time
- -20 to 60°C Ambient operating temperature range
2940207 Specifications
| Attribute | Attribute Value |
|---|---|
| Datasheet | Datasheet |
| 3D Model | 3D Model |
| Case/Package | Module |
| Operating Voltage | 48.0V (max) |
| Load Current | 100 mA |
| Input Current | 7 mA |
| Isolation Voltage | 2.5 kV |
| Current Rating (Max) | 0.007 A |
| Input Current (Min) | 7 mA |
| Maximum Forward Voltage (Max) | 24 V |
| Operating Temperature (Max) | 60 ℃ |
| Operating Temperature (Min) | -20 ℃ |
| Voltage Rating (Max) | 24 VDC |
| Operating Voltage (Min) | 3 V |
| Operating Voltage (Max) | 48 VDC |
| Input Voltage | 24 VDC |
| Show | |
| Size-Length | 56 mm |
| Size-Width | 6.2 mm |
| Size-Height | 80 mm |
| Color | Green |
| Operating Temperature | -20℃ ~ 60℃ |
| Product Lifecycle Status | Active |
| Packaging | Bulk |
| RoHS | RoHS Compliant |
| Lead-Free Status | Lead Free |
| REACH SVHC Compliance | No SVHC |
| REACH SVHC Compliance Edition | 2015/06/15 |
| HTS Code | 8536410060 |
| ECCN Code | EAR99 |
