Attribute | Attribute Value |
---|---|
Datasheet | Datasheet |
3D Model | 3D Model |
Mounting Style | Through Hole |
Number of Pins | 3 Pin |
Case/Package | TO-92-3 |
Frequency | 250 MHz |
Voltage Rating (DC) | -40.0 V |
Current Rating | -200 mA |
Power Rating | 625 mW |
Number of Positions | 3 Position |
Polarity | PNP |
Power Dissipation | 625 mW |
Gain Bandwidth Product | 250 MHz |
Breakdown Voltage (Collector to Emitter) | 40 V |
Continuous Collector Current | 0.2A |
hFE Min | 100 @10mA, 1V |
hFE Max | 300 |
Input Power (Max) | 625 mW |
DC Current Gain (hFE) | 30 |
Operating Temperature (Max) | 150 ℃ |
Operating Temperature (Min) | -55 ℃ |
Power Dissipation (Max) | 625 mW |
Show | |
Size-Length | 5.2 mm |
Size-Width | 4.19 mm |
Size-Height | 5.33 mm |
Operating Temperature | -55℃ ~ 150℃ (TJ) |
Product Lifecycle Status | Active |
Packaging | Bulk |
RoHS | RoHS Compliant |
Lead-Free Status | Lead Free |
REACH SVHC Compliance | No SVHC |
REACH SVHC Compliance Edition | 2015/06/15 |
ECCN Code | EAR99 |
