Description

The 2N7002BKV is a dual N-channel enhancement-mode FET in a surface-mount plastic package using Trench MOSFET technology. It is suitable for relay driver, high-speed line driver, low-side load-switch and switching circuit applications.
Logic-level compatible
Very fast switching

Show

2N7002BKV Specifications

Attribute	Attribute Value

Datasheet	Datasheet
3D Model	3D Model
Mounting Style	Surface Mount
Number of Pins	6 Pin
Case/Package	SOT-666
Number of Positions	6 Position
Drain to Source Resistance (on) (Rds)	1 Ω
Polarity	Dual N-Channel
Power Dissipation	525 mW
Threshold Voltage	1.6 V
Drain to Source Voltage (Vds)	60 V
Continuous Drain Current (Ids)	0.34A
Input Capacitance (Ciss)	33pF @10V(Vds)
Operating Temperature (Max)	150 ℃
Operating Temperature (Min)	-55 ℃
Power Dissipation (Max)	0.41 W
	Show
Size-Length	1.7 mm
Size-Width	1.3 mm
Size-Height	0.6 mm
Operating Temperature	-55℃ ~ 150℃
Product Lifecycle Status	Unknown
Packaging	Tape & Reel (TR)
RoHS	RoHS Compliant
Lead-Free Status	Lead Free
REACH SVHC Compliance	No SVHC
REACH SVHC Compliance Edition	2015/12/17
HK STC License	NLR
