This PNP transistor is designed for general purpose amplifier applications. This device is housed in the SC−75/SOT−416/SC−90 package which is designed for low power surface mount applications, where board space is at a premium.
Features
• Reduces Board Space
• High hFE, 210−460 (typical)
• Low VCE(sat), < 0.5 V
• Available in 8 mm, 7−inch/3000 Unit Tape and Reel
• Pb−Free Packages are Available

Show

2SA1774 Specifications

Attribute	Attribute Value

Datasheet	Datasheet
3D Model	3D Model
Mounting Style	Surface Mount
Case/Package	SC-75-3
Voltage Rating (DC)	-50.0 V
Current Rating	-100 mA
Polarity	PNP
Power Dissipation	150 mW
Breakdown Voltage (Collector to Emitter)	50 V
Continuous Collector Current	0.1A
hFE Min	120
hFE Max	560
Operating Temperature (Max)	150 ℃
Operating Temperature (Min)	-55 ℃
	Show
Size-Length	1.6 mm
Size-Width	0.8 mm
Size-Height	0.75 mm
Product Lifecycle Status	Unknown
Packaging	Tape
Minimum Packing Quantity	3000
RoHS	RoHS Compliant
Lead-Free Status	Contains Lead
