Attribute | Attribute Value |
---|---|
Datasheet | Datasheet |
3D Model | 3D Model |
Mounting Style | Surface Mount |
Number of Pins | 6 Pin |
Case/Package | SMD-DIP-6 |
Output Voltage | 60.0 V |
Number of Channels | 1 Channel |
Number of Positions | 6 Position |
Forward Voltage | 1.2 V |
Input Current | 80.0 mA |
Power Dissipation | 0.25 W |
Rise Time | 5 µs |
Isolation Voltage | 1.5 kV |
Forward Current | 80 mA |
Output Voltage (Max) | 30 V |
Input Current (Min) | 3 A |
Reverse Breakdown Voltage | 3 V |
Maximum Forward Voltage (Max) | 1.5 V |
Forward Current (Max) | 80 mA |
Fall Time | 100 µs |
Operating Temperature (Max) | 100 ℃ |
Operating Temperature (Min) | -40 ℃ |
Power Dissipation (Max) | 250 mW |
Show | |
Size-Width | 6.6 mm |
Size-Height | 3.53 mm |
Operating Temperature | -40℃ ~ 100℃ |
Product Lifecycle Status | Active |
Packaging | Tape & Reel (TR) |
RoHS | RoHS Compliant |
Lead-Free Status | Lead Free |
REACH SVHC Compliance | No SVHC |
REACH SVHC Compliance Edition | 2015/06/15 |
ECCN Code | EAR99 |
