56200C - muRata
Manufacturer:
muRata
ManyChip's Part#:
MC48533600
Category:
Transformer
Package:
SIP
Datasheet:
Datasheet 3D Model
Description:
Current Transformer 1:200 500VDC 1.87Ω/2.81Ω Prim. DCR 80000uH/150000uH Prim. 10000mA Prim. 3Term. PC Pin Thru-Hole
Stock Locations:
Availability:
79 pcs In Stock
MOQ:
1 pcs
Unit Price:
$ 1.71

Updated at 01/11/2025 10:30:15(UTC+8)

Certifications

ManyChip is committed to product quality and safety with ISO 9001, ISO 13485, ISO 45001, UL, RoHS, CQC and REACH certifications.

Description

56200C is manufactured by Murata Power and is categorized in the Current Sense Transformers category. 56200C is described as CURR SENSE XFMR 10A T/H. Perfect Parts is a supplier of Transformers and other Miscellaneous.

Show

56200C Specifications

Attribute	Attribute Value

Datasheet	Datasheet
3D Model	3D Model
Mounting Style	Through Hole
Number of Pins	3 Pin
Case/Package	SIP
Inductance	80 mH
Input Current	10 A
Isolation Voltage	500 VDC
DC Resistance (DCR)	2.81 Ω
Operating Temperature (Max)	85 ℃
Operating Temperature (Min)	-40 ℃
	Show
Size-Length	16.79 mm
Size-Width	8.89 mm
Size-Height	20.19 mm
Weight	5.70 g
Operating Temperature	-40℃ ~ 85℃
Product Lifecycle Status	Active
Packaging	Tube
RoHS	RoHS Compliant
Lead-Free Status	Lead Free
REACH SVHC Compliance Edition	2015/12/17
ECCN Code	EAR99
