74HCT165N - NXP
Manufacturer:
NXP
ManyChip's Part#:
MC160945539
Category:
Shift Register IC
Package:
DIP
Datasheet:
Datasheet 3D Model
Description:
NXP 74HCT165N Shift Register, 74HCT165, Parallel to Serial, 1Element, 8Bit, DIP, 16Pins
Stock Locations:
Availability:
299 pcs In Stock
MOQ:
1 pcs
Unit Price:
$ 0.7

Updated at 01/11/2025 10:30:15(UTC+8)

Certifications

ManyChip is committed to product quality and safety with ISO 9001, ISO 13485, ISO 45001, UL, RoHS, CQC and REACH certifications.

Description

The 74HCT165N is a 8-bit serial or parallel-in/serial-out Shift Register features a serial data input (DS), eight parallel data inputs (D0 to D7) and two complementary serial outputs (Q7 and Q7\\). When the parallel load input (PL\\) is low the data from D0 to D7 is loaded into the shift register asynchronously. When PL\ is high data enters the register serially at DS. When the clock enable input (CE\\) is low data is shifted on the low-to-high transitions of the CP input. A high on CE\ will disable the CP input. Inputs include clamp diodes, this enables the use of current limiting resistors to interface inputs to voltages in excess of VCC.
Asynchronous 8-bit parallel load
Synchronous serial input
TTL Input level
Complies with JEDEC standard No. 7A

Show

74HCT165N Specifications

Attribute	Attribute Value

Datasheet	Datasheet
3D Model	3D Model
Mounting Style	Through Hole
Number of Pins	16 Pin
Case/Package	DIP
Frequency	48.0 MHz
Digital Logic Level	TTL
Supply Voltage (DC)	5.00 V, 6.00 V (max)
Number of Circuits	8 Circuit
Number of Positions	16 Position
Number of Bits	8 Bit
Number of Gates	1 Gate
Input Capacitance	3.50 pF
Operating Temperature (Max)	125 ℃
Operating Temperature (Min)	-40 ℃
Supply Voltage (Max)	5.5 V
Supply Voltage (Min)	4.5 V
	Show
Size-Length	19.5 mm
Size-Width	6.48 mm
Size-Height	4.2 mm
Product Lifecycle Status	Unknown
Packaging	Each
RoHS	RoHS Compliant
Lead-Free Status	Lead Free
REACH SVHC Compliance	No SVHC
REACH SVHC Compliance Edition	2015/12/17
