74LVT125D Specifications
| Attribute | Attribute Value |
|---|---|
| Datasheet | Datasheet |
| 3D Model | 3D Model |
| Mounting Style | Surface Mount |
| Number of Pins | 14 Pin |
| Case/Package | SOP |
| Supply Voltage (DC) | 3.30 V, 3.60 V (max) |
| Number of Outputs | 4 Output |
| Number of Channels | 4 Channel |
| Number of Bits | 1 Bit |
| Quiescent Current | 2.00 mA |
| Number of Inputs | 4 Input |
| Show | |
| Size-Length | 8.65 mm |
| Size-Width | 3.9 mm |
| Product Lifecycle Status | Unknown |
| Packaging | Tube |
| RoHS | RoHS Compliant |
| Lead-Free Status | Lead Free |
