Description

AC162050 is a MPLAB ICD 8 pin header interface required for debugging PIC12F629/675. The header interface provides In-Circuit Debugging capability to the 8 pin device. The header interface is connected in place of the target device and houses a standard MPLAB ICD 2 connector. In-circuit debugging is done via an MPLAB ICD 2. Once the code is debugged, the debugged software can then be programmed into the device and installed in the board replacing the header.

Show

AC162050 Specifications

Attribute	Attribute Value

Datasheet	Datasheet
3D Model	3D Model
Mounting Style	Through Hole
Number of Pins	84 Pin
Case/Package	PDIP
	Show
Product Lifecycle Status	Unknown
Packaging	Bulk
RoHS	RoHS Compliant
Lead-Free Status	Lead Free
REACH SVHC Compliance	No SVHC
REACH SVHC Compliance Edition	2015/12/17
HTS Code	8473309100
ECCN Code	EAR99
