ANALOG DEVICES AD5308ARUZ Digital to Analogue Converter, 8Bit, 167KSPS, Serial, 2.5V to 5.5V, TSSOP, 16Pins
Stock Locations:
Availability:
281 pcs In Stock
MOQ:
1 pcs
Unit Price:
$ 4.08

Updated at 02/11/2025 10:30:15(UTC+8)

Certifications

ManyChip is committed to product quality and safety with ISO 9001, ISO 13485, ISO 45001, UL, RoHS, CQC and REACH certifications.

Description

The AD5308ARUZ is an octal 8-bit buffered voltage output Digital-to-analog Converter (DAC) operates from a single 2.5 to 5.5V supply, consuming 0.7mA typical at 3V. Its on-chip output amplifier allows the outputs to swing rail-to-rail with a slew rate of 0.7V/µs. The AD5308 uses a versatile 3-wire serial interface that operates at clock rates up to 30MHz and is compatible with standard SPI, QSPI, MICROWIRE and DSP interface standards. The references for the eight DACs are derived from two reference pins. This reference inputs can be configured as buffered, un-buffered or VDD inputs. The parts incorporates a power-on reset circuit, which ensures that the DAC outputs power up to 0V and remain there until a valid write to the device takes place. The outputs of DAC may be updated simultaneously using the asynchronous LDAC input. The parts contain a power-down feature that reduces the current consumption of the device to 400nA at 5V.
Guaranteed monotonic by design over all codes
Double-buffered input logic
Programmability
Individual channel power-down
Simultaneous update of outputs
On-chip rail-to-rail output buffer amplifiers

Show

AD5308ARUZ Specifications

Attribute	Attribute Value

Datasheet	Datasheet
3D Model	3D Model
Mounting Style	Surface Mount
Number of Pins	16 Pin
Case/Package	TSSOP-16
Number of Outputs	8 Output
Supply Current	1.00 mA
Number of Channels	8 Channel
Number of Positions	16 Position
Number of Bits	8 Bit
Power Dissipation	0.005 W
Sample Rate	167 kHz
Resolution (Bits)	8.0 Bit
Operating Temperature (Max)	125 ℃
Operating Temperature (Min)	-40 ℃
Power Dissipation (Max)	5 mW
Number of DACs	8 DAC
Supply Voltage	2.5V ~ 5.5V
	Show
Size-Length	5 mm
Size-Width	4.4 mm
Size-Height	1.05 mm
Operating Temperature	-40℃ ~ 105℃
Product Lifecycle Status	Active
Packaging	Each
RoHS	RoHS Compliant
Lead-Free Status	Contains Lead
REACH SVHC Compliance	No SVHC
Mil-Spec	No
REACH SVHC Compliance Edition	2015/12/17
