AD5593RBRUZ - ADI
Manufacturer:
ADI
ManyChip's Part#:
MC284158
Category:
Analog to Digital, ADC IC
Package:
TSSOP-16
Datasheet:
Datasheet 3D Model
Description:
ANALOG DEVICES AD5593RBRUZ Analogue to Digital Converter, 12Bit, 400KSPS, 2.7V, 5.5V, TSSOP
Stock Locations:
Availability:
288 pcs In Stock
MOQ:
1 pcs
Unit Price:
$ 16.79

Updated at 17/06/2025 10:30:15(UTC+8)

Certifications

ManyChip is committed to product quality and safety with ISO 9001, ISO 13485, ISO 45001, UL, RoHS, CQC and REACH certifications.

Description

The AD5593RBRUZ is a 8-channel ADC/DAC with on-chip reference and I²C interface. It has eight input/output pins, which can be independently configured as digital-to-analog converter outputs, analog-to-digital converter inputs, digital outputs or digital inputs. When an I/O pin is configured as an analog output, it is driven by a 12-bit DAC. The output range of the DAC is 0 to VREF or 0 to 2 x VREF. When an I/O pin is configured as an analog input, it is connected to a 12-bit ADC via an analog multiplexer. The input range of the ADC is 0 to VREF or 0 to 2 x VREF. The I/O pins can also be configured to be general-purpose, digital input or output pins. The state of the GPIO pins can be set or read back by accessing the GPIO write data register and GPIO read configuration registers respectively via an I²C write or read operation.
Integrated temperature sensor
ADC differential nonlinearity
Channel-to-channel isolation
ADC power supply rejection ratio
Track-and-hold acquisition time
Signal-to-(noise + distortion) ratio
Peak harmonic or spurious noise
DAC relative accuracy or integral nonlinearity

Show

AD5593RBRUZ Specifications

Attribute	Attribute Value

Datasheet	Datasheet
3D Model	3D Model
Mounting Style	Surface Mount
Number of Pins	16 Pin
Case/Package	TSSOP-16
Supply Voltage (DC)	2.70V (min)
Number of Circuits	1 Circuit
Number of Channels	8 Channel
Number of Positions	16 Position
Number of Bits	12 Bit
Sample Rate	400 kHz
Number of ADCs	1 ADC
Operating Temperature (Max)	105 ℃
Operating Temperature (Min)	-40 ℃
Number of DACs	8 DAC
Supply Voltage	1.8V ~ 5.5V
Supply Voltage (Max)	5.5 V
Supply Voltage (Min)	2.7 V
	Show
Size-Length	5.1 mm
Size-Width	4.5 mm
Size-Height	1.05 mm
Operating Temperature	-40℃ ~ 105℃
Product Lifecycle Status	Active
Packaging	Cut Tape (CT)
RoHS	RoHS Compliant
Lead-Free Status	Contains Lead
REACH SVHC Compliance	No SVHC
REACH SVHC Compliance Edition	2015/12/17
ECCN Code	EAR99
