TS3USB30ERSWR - TI
Manufacturer:
TI
ManyChip's Part#:
MC360520
Category:
Analog Switch Ic, Analog Switch Multiplexer
Package:
UQFN-10
Datasheet:
Datasheet 3D Model
Description:
TEXAS INSTRUMENTS TS3USB30ERSWR Analog Switch, 2Channels, 10Ω, 3V to 4.3V, QFN, 10Pins
Stock Locations:
Availability:
2,136 pcs In Stock
MOQ:
1 pcs
Unit Price:
$ 0.63

Updated at 17/06/2025 10:30:15(UTC+8)

Certifications

ManyChip is committed to product quality and safety with ISO 9001, ISO 13485, ISO 45001, UL, RoHS, CQC and REACH certifications.

Description

The TS3USB30ERSWR is a high-bandwidth 1:2 Analog Switch specially designed for the switching of high-speed USB 2.0 signals in handset with limited USB I/Os. The wide bandwidth (900MHz) of this switch allows signals to pass with minimum edge and phase distortion. The device multiplexes differential outputs from an USB host device to one of two corresponding outputs, or from two different hosts to one corresponding output. The switch is bidirectional and offers little or no attenuation of the high-speed signals at the outputs. It is designed for low bit-to-bit skew and high channel-to-channel noise isolation and is compatible with various standards, such as high-speed USB 2.0 (480Mbps). The TS3USB30E integrates ESD protection cells on all pins.
IOFF Supports partial power-down-mode operation
Low power consumption
Latch-up performance exceeds 100 mA per JESD 78, class II
ESD performance I/O port to GND
Green product and no Sb/Br
Device has limited built-in ESD protection, leads should be shorted together or the device placed in conductive foam during storage or handling to prevent electrostatic damage to the MOS gates.

Show

TS3USB30ERSWR Specifications

Attribute	Attribute Value

Datasheet	Datasheet
3D Model	3D Model
Mounting Style	Surface Mount
Number of Pins	10 Pin
Case/Package	UQFN-10
Supply Voltage (DC)	3.00V ~ 4.30V
Number of Outputs	4 Output
Supply Current	1 µA
Number of Channels	2 Channel
Number of Positions	10 Position
Bandwidth	900 MHz
Number of Inputs	2 Input
Operating Temperature (Max)	85 ℃
Operating Temperature (Min)	-40 ℃
3dB Bandwidth	900 MHz
Supply Voltage	3V ~ 4.3V
Supply Voltage (Max)	4.3 V
Supply Voltage (Min)	3 V
	Show
Size-Length	1.85 mm
Size-Width	1.45 mm
Size-Height	0.5 mm
Operating Temperature	-40℃ ~ 85℃
Product Lifecycle Status	Active
Packaging	Tape & Reel (TR)
RoHS	RoHS Compliant
Lead-Free Status	Lead Free
REACH SVHC Compliance	No SVHC
REACH SVHC Compliance Edition	2015/06/15
ECCN Code	EAR99
