- AD5624BRMZ - ADI
-
Manufacturer:ADI
-
ManyChip's Part#:MC1270837
-
Category:Digital to Analog, DAC IC
-
Package:MSOP-10
-
Datasheet:Datasheet 3D Model
-
Description:Digital to Analog Converter, 12Bit, 287KSPS, Serial, 2.7V to 5.5V, MSOP, 10Pins
-
Stock Locations:
-
Availability:305 pcs In Stock
-
MOQ:1 pcs
-
Unit Price:$ 4.27
Updated at 17/06/2025 10:30:15(UTC+8)
Certifications
ManyChip is committed to product quality and safety with ISO 9001, ISO 13485, ISO 45001, UL, RoHS, CQC and REACH certifications.
Description
- The AD5624BRMZ is a low power quad 12-bit buffered voltage-out Digital-to-analog Converter (ADC) that operate from a single 2.7 to 5.5V supply and are guaranteed monotonic by design. It requires an external reference voltage to set the output range of the DAC. The part incorporates a power-on reset circuit that ensures the DAC output powers up to 0V and remains there until a valid write takes place. The parts contain a power-down feature that reduces the current consumption of the device to 480nA at 5V and provides software-selectable output loads while in power-down mode. The low power consumption of this part in normal operation makes it ideally suited to many applications. The AD5624 on-chip precision output amplifier allows rail-to-rail output swing to be achieved. It uses a versatile 3-wire serial interface that operates at clock rates up to 50 MHz and are compatible with standard SPI®, QSPI™, MICROWIRE™ and DSP interface standards.
- Guaranteed monotonic by design
- Power-on reset to zero
- Per channel power-down
AD5624BRMZ Specifications
| Attribute | Attribute Value |
|---|---|
| Datasheet | Datasheet |
| 3D Model | 3D Model |
| Mounting Style | Surface Mount |
| Number of Pins | 10 Pin |
| Case/Package | MSOP-10 |
| Supply Voltage (DC) | 5.50V (max) |
| Number of Outputs | 4 Output |
| Supply Current | 450 µA |
| Number of Channels | 4 Channel |
| Number of Positions | 10 Position |
| Number of Bits | 12 Bit |
| Power Dissipation | 4.5 mW |
| Sample Rate | 287 ksps |
| Resolution (Bits) | 12.0 Bit |
| Operating Temperature (Max) | 105 ℃ |
| Operating Temperature (Min) | -40 ℃ |
| Power Dissipation (Max) | 4.5 mW |
| Number of DACs | 4 DAC |
| Supply Voltage | 2.7V ~ 5.5V |
| Supply Voltage (Max) | 5.5 V |
| Supply Voltage (Min) | 2.7 V |
| Show | |
| Size-Length | 3 mm |
| Size-Width | 3 mm |
| Size-Height | 0.85 mm |
| Operating Temperature | -40℃ ~ 105℃ |
| Product Lifecycle Status | Active |
| Packaging | Tube |
| RoHS | RoHS Compliant |
| Lead-Free Status | Lead Free |
| REACH SVHC Compliance | No SVHC |
| Mil-Spec | No |
