AD650JNZ - ADI
Manufacturer:
ADI
ManyChip's Part#:
MC512783
Category:
Analog to Digital, ADC IC
Package:
PDIP-14
Datasheet:
Datasheet 3D Model
Description:
ANALOG DEVICES AD650JNZ Voltage to Frequency Converter, 1MHz, 0Hz to 1MHz, 0.02%, ± 9V to ± 18V, DIP, 14Pins
Stock Locations:
Availability:
2,178 pcs In Stock
MOQ:
1 pcs
Unit Price:
$ 15.62

Updated at 17/06/2025 10:30:15(UTC+8)

Certifications

ManyChip is committed to product quality and safety with ISO 9001, ISO 13485, ISO 45001, UL, RoHS, CQC and REACH certifications.

Description

The AD650JNZ is a Voltage-to-Frequency Converter provides a combination of high frequency operation and low nonlinearity previously unavailable in monolithic form. The inherent monotonicity of the V/F transfer function makes the AD650 useful as a high-resolution analog-to-digital converter. A flexible input configuration allows a wide variety of input voltage and current formats to be used and an open-collector output with separate digital ground allows simple interfacing to either standard logic families or opto-couplers. The linearity error of the AD650 is typically 20ppm (0.002% of full scale) and 50ppm (0.005%) maximum at 10kHz full scale. This corresponds to approximately 14-bit linearity in an analog-to-digital converter circuit. Higher full-scale frequencies or longer count intervals can be used for higher resolution conversions. The AD650 has useful dynamic range of six decades allowing extremely high resolution measurements.
V/F conversion to 1MHz
Reliable monolithic construction
Input offset trimmable to zero
CMOS or TTL compatible
Unipolar, bipolar or differential V/F
Available in surface mount
