- GENERAL DESCRIPTION
- The AD7682/AD7689 are 4-channel/8-channel, 16-bit, charge redistribution successive approximation register (SAR) analog to-digital converters (ADCs) that operate from a single power
- supply, VDD.
- The AD7682/AD7689 contain all components for use in a multichannel, low power data acquisition system, including a true 16-bit SAR ADC with no missing codes; a 4-channel(AD7682) or 8-channel (AD7689), low crosstalk multiplexer useful for configuring the inputs as single ended (with or without ground sense), differential, or bipolar; an internal low drift reference (selectable 2.5 V or 4.096 V) and buffer; a temperature sensor; a selectable one-pole filter; and a sequencer that is useful when channels are continuously scanned in order.
AD7689BCPZRL7 Specifications
| Attribute | Attribute Value |
|---|---|
| Datasheet | Datasheet |
| 3D Model | 3D Model |
| Mounting Style | Surface Mount |
| Number of Pins | 20 Pin |
| Case/Package | LFCSP-20 |
| Number of Circuits | 1 Circuit |
| Number of Channels | 8 Channel |
| Number of Bits | 16 Bit |
| Power Dissipation | 15.5 mW |
| Sample Rate | 250 ksps |
| Power Consumption | 15.5 mW |
| Resolution (Bits) | 16.0 Bit |
| Number of ADCs | 1 ADC |
| Number of Inputs | 8 Input |
| Operating Temperature (Max) | 85 ℃ |
| Operating Temperature (Min) | -40 ℃ |
| Power Dissipation (Max) | 21 mW |
| Show | |
| Size-Width | 4 mm |
| Operating Temperature | -40℃ ~ 85℃ |
| Product Lifecycle Status | Active |
| Packaging | Tape & Reel (TR) |
| RoHS | RoHS Compliant |
| Lead-Free Status | Lead Free |
| Mil-Spec | No |
