AD8000YRDZ - ADI
Manufacturer:
ADI
ManyChip's Part#:
MC261320
Category:
Operational Amplifier, OP Amp IC
Package:
SOIC-8
Datasheet:
Datasheet 3D Model
Description:
ANALOG DEVICES AD8000YRDZ Operational Amplifier, Single, 1 Amplifier, 1.5MHz, 4100V/µs, 4.5V to 12V, SOIC, 8Pins
Stock Locations:
Availability:
3 pcs In Stock
MOQ:
1 pcs
Unit Price:
$ 3.97

Updated at 02/11/2025 10:30:15(UTC+8)

Certifications

ManyChip is committed to product quality and safety with ISO 9001, ISO 13485, ISO 45001, UL, RoHS, CQC and REACH certifications.

Description

The AD8000YRDZ is a 1.5GHz Ultrahigh Speed Operational Amplifier ideal for a variety of applications including high speed instrumentation. Using eXtra Fast Complementary Bipolar (XFCB) process, the high performance current Feedback amplifier can achieve a small signal bandwidth of 1.5GHz and a slew rate of 4100V/µs. It has low spurious-free dynamic range (SFDR) of 75dBc at 20MHz and input voltage noise of 1.6nV/√Hz. The AD8000 can drive over 100mA of load current with minimal distortion. The amplifier can operate on +5V to ±6V. With a differential gain of 0.02%, differential phase of 0.01° and 0.1dB flatness out to 170MHz, it has excellent video specifications, which ensure that even the most demanding video systems maintain excellent fidelity. The AD8000 power-down mode reduces the supply current to 1.3mA.
12ns 0.1% Settling time
Excellent video specifications
0.02% Differential gain
Low distortion over wide bandwidth
Low noise
100mA High output current
13.5mA Supply current
ESD sensitive device, take proper precaution while handling the device.

Show

AD8000YRDZ Specifications

Attribute	Attribute Value

Datasheet	Datasheet
3D Model	3D Model
Mounting Style	Surface Mount
Number of Pins	8 Pin
Case/Package	SOIC-8
Supply Voltage (DC)	5.00 V
Output Current	70mA @5V
Supply Current	13.5 mA
Number of Circuits	1 Circuit
Number of Channels	1 Channel
Number of Positions	8 Position
Common Mode Rejection Ratio	51 dB
Input Capacitance	3.60 pF
Bandwidth	1.5 GHz
Slew Rate	4.10 kV/μs
Gain Bandwidth Product	1.5 MHz
Input Impedance	2.00 MΩ
Gain	1.00 dB
Input Offset Voltage	1 mV
Input Bias Current	5 µA
Operating Temperature (Max)	125 ℃
Operating Temperature (Min)	-40 ℃
3dB Bandwidth	1.58 GHz
Gain Bandwidth	51 dB
Minimum CMRR Range	51 dB
Supply Voltage	4.5V ~ 12V
Supply Voltage (Max)	12 V
Supply Voltage (Min)	4.5 V
	Show
Size-Length	4.9 mm
Size-Width	3.9 mm
Size-Height	1.65 mm
Operating Temperature	-40℃ ~ 125℃
Product Lifecycle Status	Active
Packaging	Each
RoHS	RoHS Compliant
Lead-Free Status	Contains Lead
REACH SVHC Compliance	No SVHC
Mil-Spec	No
REACH SVHC Compliance Edition	2015/12/17
ECCN Code	EAR99
