Image is for your reference only,please check specifications for details

AD8436 - ADI
Manufacturer:
ADI
ManyChip's Part#:
MC114688255
Category:
Microprocessor Development Kit
Datasheet:
Datasheet 3D Model
Description:
ANALOG DEVICES AD8436 True RMS to DC Converter, DC Output Offset, Precision DC Output Buffer, ESD Protected
Stock Locations:
Availability:
266 pcs In Stock
MOQ:
1 pcs
Unit Price:
$ 135.74

Updated at 29/11/2025 10:30:15(UTC+8)

Certifications

ManyChip is committed to product quality and safety with ISO 9001, ISO 13485, ISO 45001, UL, RoHS, CQC and REACH certifications.

Description

The AD8436 is a new generation, translinear precision, low power, true rms to dc converter that is loaded with options. It computes a precise dc equivalent of the rms value ac waveforms, including complex patterns such as those generated by switch mode power supplies and triacs. Its accuracy spans a wide range of input levels and temperatures. The AD8436 delivers instant true rms results for less cost than misleading peak, averaging, or digital solutions. On-board buffer amplifiers enable the widest range of options for any rms to dc converter available, regardless of cost. For minimal applications, only a single external averaging capacitor is required. The built in high impedance FET buffer provides an interface for external attenuators, frequency compensation, or driving low impedance loads.
Delivers true rms or average rectified value of an ac waveform
Fast settling at all input levels
100 µV rms to 3 V rms (8.5 V p-p) full-scale input range
Wide bandwidth: 1 MHz for -3 dB (300 mV)
Zero converter dc output offset
No residual switching products
Specified at 300 mV rms input
Accurate conversion with crest factors up to 10
High Z FET separately powered input buffer
Precision dc output buffer

Show

AD8436 Specifications

Attribute	Attribute Value

Datasheet	Datasheet
3D Model	3D Model
	Show
Product Lifecycle Status	Unknown
RoHS	RoHS Compliant
REACH SVHC Compliance	No SVHC
REACH SVHC Compliance Edition	2015/12/17
