AD9747BCPZ - ADI
Manufacturer:
ADI
ManyChip's Part#:
MC170271
Category:
Digital to Analog, DAC IC
Package:
LFCSP-72
Datasheet:
Datasheet 3D Model
Description:
ANALOG DEVICES AD9747BCPZ Digital to Analog Converter, 16Bit, 250MSPS, Serial, 1.7V to 1.9V, 3.13V to 3.47V, CSP, 72Pins
Stock Locations:
Availability:
259 pcs In Stock
MOQ:
1 pcs
Unit Price:
$ 56.34

Updated at 17/06/2025 10:30:15(UTC+8)

Certifications

ManyChip is committed to product quality and safety with ISO 9001, ISO 13485, ISO 45001, UL, RoHS, CQC and REACH certifications.

Description

The AD9747BCPZ is a pin-compatible 16-bit high dynamic range dual Digital-to-analog Converter (DAC) with sample rates of up to 250 MSPS. The device includes specific features for direct conversion transmits applications, including gain and offset compensation and it interfaces seamlessly with analog quadrature modulators. Proprietary, dynamic output architecture permits synthesis of analog outputs even above Nyquist by shifting energy away from the fundamental and into the image frequency. A serial peripheral interface (SPI) port provides full programmability. In addition, some pin-programmable features are offered for those applications without a controller.
Low noise and intermodulation distortion
LVCMOS Inputs with dual-port or optional interleaved 1-port operation
Auxiliary 10-bit current DAC with source/sink capability for external offset nulling
Internal 1.2V precision reference voltage source
315mW Power dissipation

Show

AD9747BCPZ Specifications

Attribute	Attribute Value

Datasheet	Datasheet
3D Model	3D Model
Mounting Style	Surface Mount
Number of Pins	72 Pin
Case/Package	LFCSP-72
Number of Outputs	2 Output
Supply Current	56 mA
Number of Channels	2 Channel
Number of Positions	72 Position
Number of Bits	16 Bit
Power Dissipation	0.355 W
Sample Rate	250 Msps
Resolution (Bits)	16.0 Bit
Operating Temperature (Max)	85 ℃
Operating Temperature (Min)	-40 ℃
Power Dissipation (Max)	355 mW
Number of DACs	2 DAC
Supply Voltage (Max)	3.47 V
Supply Voltage (Min)	3.13 V
	Show
Size-Length	10 mm
Size-Width	10 mm
Size-Height	0.8 mm
Operating Temperature	-40℃ ~ 85℃
Product Lifecycle Status	Active
Packaging	Tray
RoHS	RoHS Compliant
Lead-Free Status	Lead Free
REACH SVHC Compliance	No SVHC
Mil-Spec	No
REACH SVHC Compliance Edition	2016/06/20
ECCN Code	EAR99
