Description

The ADDI7013BBCZ is a dual-channel, CCD Signal Processor with precision timing core. Each channel is specified at pixel rates of up to 75MHz and consists of a complete analog front end (AFE) with analog-to-digital conversion. The Precision Timing® core allows adjustment of the correlated double sampler (CDS) and horizontal clocks with 210ps resolution at 75MHz operation. There are eight independent horizontal clock outputs with programmable drive strength to support a variety of CCD timing requirements. Each analog front end includes black level clamping, a CDS, a VGA and a 16-bit, 75MSPS analog-to-digital converter (ADC). Operation is programmed using a 3-wire serial interface.
Differential analog inputs
0 to 36dB, 10-bit Variable gain amplifier (VGA)
16-bit, 75MSPS analog-to-digital converter (ADC)
Precision Timing core with 210ps resolution at 75MHz
8 Independent H-clock phases with programmable drive strength (3.6V maximum swing)
4 General-purpose outputs (GPO)
On-chip sync generator with external sync input
Reduced range LVDS outputs with single clock lane

Show

ADDI7013BBCZ Specifications

Attribute	Attribute Value

Datasheet	Datasheet
3D Model	3D Model
Mounting Style	Surface Mount
Number of Pins	76 Pin
Case/Package	BGA-76
Number of Channels	2 Channel
Number of Positions	76 Position
Sample Rate	75000 KSPS
Number of ADCs	2 ADC
Operating Temperature (Max)	85 ℃
Operating Temperature (Min)	-40 ℃
	Show
Size-Length	6 mm
Size-Width	6 mm
Operating Temperature	-40℃ ~ 85℃
Product Lifecycle Status	Active
Packaging	Tray
RoHS	RoHS Compliant
Lead-Free Status	Lead Free
REACH SVHC Compliance	No SVHC
REACH SVHC Compliance Edition	2015/12/17
ECCN Code	EAR99
