Description

The ADE7880ACPZ is a Polyphase Multifunction Energy Metering IC with harmonic monitoring. It incorporates second-order sigma-delta (Σ-Δ) analogue-to-digital converters (ADCs), a digital integrator, reference circuitry and all of the signal processing required to perform the total (fundamental and harmonic) active and apparent energy measurements, rms calculations as well as fundamental-only active and reactive energy measurements. In addition, the ADE7880 computes the rms of harmonics on the phase and neutral currents and on the phase voltages, together with the active, reactive and apparent powers and the power factor and harmonic distortion on each harmonic for all phases. Total harmonic distortion (THD) is computed for all currents and voltages. A fixed function digital signal processor (DSP) executes this signal processing. The DSP program is stored in the internal ROM memory.
High accuracy
Compatible with 3-phase, 3-wire or 4-wire (delta or wye) and other 3-phase services
Less than 1% error in harmonic current and voltage rms, harmonic active and reactive powers
Less than 0.1% error in active and fundamental reactive energy over a dynamic range of 5000:1
Less than 0.2% error in active and fundamental reactive energy over a dynamic range of 5000:1
Less than 0.1% error in voltage and current rms over a dynamic range of 1000:1
Battery supply input for missing neutral operation
ESD sensitive device, take proper precaution while handling the device.

Show

ADE7880ACPZ Specifications

Attribute	Attribute Value

Datasheet	Datasheet
3D Model	3D Model
Mounting Style	Surface Mount
Number of Pins	40 Pin
Case/Package	LFCSP-40
Supply Voltage (DC)	2.40V (min)
Supply Current	25 mA
Number of Positions	40 Position
Input Impedance	490 kΩ
Operating Temperature (Max)	85 ℃
Operating Temperature (Min)	-40 ℃
Supply Voltage	2.97V ~ 3.63V
Supply Voltage (Max)	3.7 V
Supply Voltage (Min)	2.4 V
	Show
Size-Length	6.1 mm
Size-Width	6.1 mm
Size-Height	0.75 mm
Operating Temperature	-40℃ ~ 85℃
Product Lifecycle Status	Active
Packaging	Tray
RoHS	RoHS Compliant
Lead-Free Status	Lead Free
REACH SVHC Compliance	No SVHC
REACH SVHC Compliance Edition	2015/12/17
ECCN Code	EAR99
