ADF7023BCPZ - ADI
Manufacturer:
ADI
ManyChip's Part#:
MC3190253
Category:
RF Module
Package:
LFCSP-32
Datasheet:
Datasheet 3D Model
Description:
RF Transceiver IC, 431MHz to 928MHz, FSK/GFSK, MSK, OOK, 300Kbps, 1.8V to 3.6V, LFCSP-32
Stock Locations:
Availability:
210 pcs In Stock
MOQ:
1 pcs
Unit Price:
$ 5.75

Updated at 01/11/2025 10:30:15(UTC+8)

Certifications

ManyChip is committed to product quality and safety with ISO 9001, ISO 13485, ISO 45001, UL, RoHS, CQC and REACH certifications.

Description

GENERAL DESCRIPTION
The ADF7023 is a very low power, high performance, highly integrated 2FSK/GFSK/OOK/MSK/GMSK transceiver designed for operation in the 862 MHz to 928 MHz and 431 MHz to 464 MHz frequency bands, which cover the worldwide license free ISM bands at 433 MHz, 868 MHz, and 915 MHz. It is suitable for circuit applications that operate under the European ETSI EN300-220, the North American FCC (Part 15), the Chinese short range wireless regulatory standards, or other similar regional standards. Data rates from 1 kbps to 300 kbps are supported.
FEATURES
Ultralow power, high performance transceiver
Frequency bands
862 MHz to 928 MHz
431 MHz to 464 MHz
Data rates supported
1 kbps to 300 kbps
2.2 V to 3.6 V power supply
Single-ended and differential PAs
Low IF receiver with programmable IF bandwidths 100 kHz, 150 kHz, 200 kHz, 300 kHz
Receiver sensitivity (BER)
−116 dBm at 1.0 kbps, 2FSK, GFSK
−107.5 dBm at 38.4 kbps, 2FSK, GFSK
−102.5 dBm at 150 kbps, GFSK, GMSK
−100 dBm at 300 kbps, GFSK, GMSK
−104 dBm at 19.2 kbps, OOK
Very low power consumption
12.8 mA in PHY_RX mode (maximum front-end gain)
24.1 mA in PHY_TX mode (10 dBm output, single-ended PA)
0.75 µA in PHY_SLEEP mode (32 kHz RC oscillator active)
1.28 µA in PHY_SLEEP mode (32 kHz XTAL oscillator active)
0.33 µA in PHY_SLEEP mode (Deep Sleep Mode 1)
