ADG1606BRUZ - ADI
Manufacturer:
ADI
ManyChip's Part#:
MC357546
Category:
Multiplexer IC
Package:
TSSOP-28
Datasheet:
Datasheet 3D Model
Description:
16:1 Analog Multiplexer IC, 16Circuits, 7.5Ω, 3.3V to 16V, TSSOP-28
Stock Locations:
Availability:
222 pcs In Stock
MOQ:
1 pcs
Unit Price:
$ 7.31

Updated at 17/06/2025 10:30:15(UTC+8)

Certifications

ManyChip is committed to product quality and safety with ISO 9001, ISO 13485, ISO 45001, UL, RoHS, CQC and REACH certifications.

Description

The ADG1606BRUZ is a monolithic iCMOS® Analogue Multiplexer comprising of 16 single channels and eight differential channels. This switches one of 16 inputs to a common output, as determined by the 4-bit binary address lines (A0, A1, A2 and A3). An EN input on both devices enables or disables the device. When disabled, all channels switch off. When enabled, each channel conducts equally well in both directions and has an input signal range that extends to the supplies. The ultralow on resistance and on-resistance flatness of these switches make them ideal solutions for data acquisition and gain switching applications where low distortion is critical. iCMOS® construction ensures ultralow power dissipation, making the parts ideally suited for portable and battery powered instruments.
7.5R Maximum on resistance over-temperature
THD + N=0.04% Minimum distortion
VINH=2V, VINL=0.8V, 3V logic-compatible digital inputs
No VL logic power supply required
4.5R Typical on resistance
1.1R Resistance flatness
±3.3 to ±8V Dual supply operation
3.3 to 16V Single supply operation
Rail-to-rail operation
Up to 378mA of continuous current per channel
Product features patented or proprietary protection circuitry, damage may occur on devices subjected to high energy ESD.
