Description

GENERAL DESCRIPTION
The ADG506A and ADG507A are CMOS monolithic analog multiplexers with 16 channels and dual 8 channels, respectively. The ADG506A switches one of 16 inputs to a common output, depending on the state of four binary addresses and an enable input. The ADG507A switches one of eight differential inputs to a common differential output, depending on the state of three binary addresses and an enable input. Both devices have TTL and 5 V CMOS logic compatible digital inputs.
PRODUCT HIGHLIGHTS
1\. Single/Dual Supply Specifications with a Wide Tolerance
The devices are specified in the 10.8 V to 16.5 V range for both single and dual supplies.
2\. Extended Signal Range
The enhanced LC2MOS processing results in a high break down and an increased analog signal range of VSS to VDD.
3\. Break-Before-Make Switching
Switches are guaranteed break-before-make so input signals are protected against momentary shorting.
4\. Low Leakage
Leakage currents in the range of 20 pA make these multiplexers suitable for high precision circuits.
FEATURES
44 V Supply Maximum Rating
VSS to VDD Analog Signal Range
Single/Dual Supply Specifications
Wide Supply Ranges (10.8 V to 16.5 V)
Extended Plastic Temperature Range (–408C to +858C)
Low Power Dissipation (28 mW max)
Low Leakage (20 pA typ)
Available in 28-Lead DIP, SOIC, PLCC, TSSOP and LCCC Packages
Superior Alternative to:
DG506A, Hl-506
DG507A, Hl-507

Show

ADG506ATQ Specifications
