The ADS1299IPAG is a low-noise, 8-channel 24-bit Analog Front End for biopotential measurements. The ADS1299 incorporates all commonly-required features for electroencephalogram (EEG) applications. The ADS1299 has a flexible input multiplexer per channel that can be independently connected to the internally-generated signals for test, temperature and lead-OFF detection. Additionally, any configuration of input channels can be selected. The ADS1299 operates at data rates from 250SPS to 16kSPS. Lead-OFF detection can be implemented internal to the device, either with an external pull-up or pull-down resistor or an excitation current sink or source. Multiple ADS1299 devices can be cascaded in high channel count systems in a daisy-chain configuration.
Eight low-noise PGAs and eight high-resolution simultaneous-sampling ADCs
1.0µVp-p (70Hz BW) Very low input-referred noise
5mW/channel Low power
300pA Input bias current
250SPS to 16kSPS Data rate
-110dB CMRR
Built-In bias drive amplifier, lead-OFF detection, test signals
Built-In oscillator
Internal or external reference
Flexible power-down, standby mode
Pin-compatible with the ADS1298IPAG
SPI™-compatible serial interface

Show

ADS1299IPAG Specifications

Attribute	Attribute Value

Datasheet	Datasheet
3D Model	3D Model
Mounting Style	Surface Mount
Number of Pins	64 Pin
Case/Package	TQFP-64
Supply Voltage (DC)	4.75V (min)
Power Rating	42 mW
Supply Current	7.14 mA
Number of Channels	8 Channel
Number of Positions	64 Position
Number of Bits	24 Bit
Sample Rate	16 KSPS
Power Consumption	41.0 mW
Number of ADCs	8 ADC
Operating Temperature (Max)	85 ℃
Operating Temperature (Min)	-40 ℃
Supply Voltage (Max)	5.25 V
Supply Voltage (Min)	4.75 V
	Show
Product Lifecycle Status	Active
Packaging	Tube
RoHS	RoHS Compliant
Lead-Free Status	Lead Free
REACH SVHC Compliance Edition	2015/06/15
ECCN Code	EAR99
