ADS131A04IPBSR - TI
Manufacturer:
TI
ManyChip's Part#:
MC5951710
Category:
Analog to Digital, ADC IC
Package:
TQFP-32
Datasheet:
Datasheet 3D Model
Description:
24Bit, 128KSPS, 4CH, Simultaneous Sampling, Delta-Sigma ADC 32-TQFP -40℃ to 125℃
Stock Locations:
Availability:
87 pcs In Stock
MOQ:
1 pcs
Unit Price:
$ 7.07

Updated at 02/11/2025 10:30:15(UTC+8)

Certifications

ManyChip is committed to product quality and safety with ISO 9001, ISO 13485, ISO 45001, UL, RoHS, CQC and REACH certifications.

Description

The ADS131A02 and ADS131A04 are two- and four-channel, simultaneously-sampling, 24-bit, delta-sigma (ΔΣ), analog-to-digital converters (ADCs). The wide dynamic range, scalable data rates, and internal fault monitors make the ADS131A02 and ADS131A04 ideally-suited for energy monitoring, protection, and control applications. The ADC inputs can be independently and directly interfaced to a resistor-divider network, a transformer to measure voltage or current, or a Rogowski coil to measure current. Flexible power-supply options, including an internal negative charge pump, are available to maximize the effective resolution for high dynamic range applications.
Asynchronous and synchronous master and slave interface options are available, providing ADC configuration flexibility when chaining multiple devices in a single system. Several interface checks, ADC startup checks, and data integrity checks can be enabled on the interface to report errors in the ADC and during data transfer.
The ADS131A02 and ADS131A04 support data rates up to 128 kSPS. The complete analog front-end (AFE) solutions are packaged in a 32-pin TQFP package and are specified over the industrial temperature range of –40°C to +125°C.

Show

ADS131A04IPBSR Specifications

Attribute	Attribute Value

Datasheet	Datasheet
3D Model	3D Model
Mounting Style	Surface Mount
Number of Pins	32 Pin
Case/Package	TQFP-32
Supply Voltage (DC)	3.00V (min)
Number of Channels	4 Channel
Number of Positions	32 Position
Number of Bits	24 Bit
Sample Rate	128 KSPS
Power Consumption	1.20 mW
Number of ADCs	4 ADC
Operating Temperature (Max)	125 ℃
Operating Temperature (Min)	-40 ℃
Number of Input Channels	4 Channel
Supply Voltage (Max)	5.5 V
Supply Voltage (Min)	3 V
	Show
Product Lifecycle Status	Active
Packaging	Cut Tape (CT)
RoHS	RoHS Compliant
Lead-Free Status	Lead Free
REACH SVHC Compliance Edition	2015/12/17
