Description
- If you need to translate continuous analog signals into digital data then Texas Instruments offers ADS7805UB ADC to handle that with ease. Its maximum power dissipation is 100 mW. It has a single-ended input signal. This device is based on SAR architecture. This device"s digital interface is parallel. This ADC has a resolution of 16bit. This ADC has an input voltage of ±10 V. This ADC has a temperature range of -25 °C to 85 °C.
ADS7805UB Specifications
| Attribute | Attribute Value |
|---|---|
| Datasheet | Datasheet |
| 3D Model | 3D Model |
| Mounting Style | Surface Mount |
| Number of Pins | 28 Pin |
| Case/Package | SOIC-28 |
| Digital Logic Level | SAR |
| Operating Voltage | 4.75V ~ 5.25V |
| Supply Current | 16.0 mA |
| Number of Circuits | 1 Circuit |
| Number of Channels | 1 Channel |
| Number of Bits | 16 Bit |
| Power Dissipation | 100 mW |
| Sample Rate | 100 ksps |
| Power Consumption | 81.5 mW |
| Number of ADCs | 1 ADC |
| Number of Inputs | 1 Input |
| Operating Temperature (Max) | 85 ℃ |
| Operating Temperature (Min) | -25 ℃ |
| Power Dissipation (Max) | 100 mW |
| Number of Input Channels | 1 Channel |
| Show | |
| Size-Length | 18 mm |
| Size-Width | 7.52 mm |
| Size-Height | 2.35 mm |
| Operating Temperature | -25℃ ~ 85℃ |
| Product Lifecycle Status | Active |
| Packaging | Tube |
| RoHS | RoHS Compliant |
| Lead-Free Status | Lead Free |
