- ADUM1100BRZ - ADI
-
Manufacturer:ADI
-
ManyChip's Part#:MC222145
-
Category:Interface Isolator, Digital Isolator
-
Package:SOIC-8
-
Datasheet:Datasheet 3D Model
-
Description:Digital Isolator, 1Channel, 18ns, 3V, 5.5V, SOIC, 8Pins
-
Stock Locations:
-
Availability:271 pcs In Stock
-
MOQ:1 pcs
-
Unit Price:$ 4.05
Updated at 01/11/2025 10:30:15(UTC+8)
Certifications
ManyChip is committed to product quality and safety with ISO 9001, ISO 13485, ISO 45001, UL, RoHS, CQC and REACH certifications.
Description
- The ADUM1100 series Digital Isolator combines high speed CMOS and monolithic air core transformer technology. This isolation component provides outstanding performance characteristics superior to alternatives, such as optocoupler devices. Configured as a pin-compatible replacement for existing high speed optocouplers, the ADuM1100 supports data rates as high as 25 and 100Mbps. It operates with a voltage supply ranging from 3 to 5.5V, boasts a propagation delay of <18ns and edge asymmetry of <2ns and is compatible with temperatures up to 125°C. It operates at very low power, less than 0.9mA of quiescent current (sum of both sides) and a dynamic current of less than 160µA per Mbps of data rate. Unlike other optocoupler alternatives, the ADuM1100 provides dc correctness with a patented refresh feature that continuously updates the output signal.
- >25kV/µs High common-mode transient immunity
- Low power operation
- High data rate of DC to 100Mbps (NRZ)
ADUM1100BRZ Specifications
| Attribute | Attribute Value |
|---|---|
| Datasheet | Datasheet |
| 3D Model | 3D Model |
| Mounting Style | Surface Mount |
| Number of Pins | 8 Pin |
| Case/Package | SOIC-8 |
| Supply Voltage (DC) | 5.00 V |
| Rise/Fall Time | 3 ns |
| Output Current | ≤20.0 mA |
| Supply Current | 9.00 mA |
| Number of Channels | 1 Channel |
| Number of Positions | 8 Position |
| Power Dissipation | 240 mW |
| Data Rate | 100 Mbps |
| Rise Time | 3 ns |
| Isolation Voltage | 2.5 kVrms |
| Input Current (Min) | 10 μA |
| Maximum Forward Voltage (Max) | 5 V |
| Fall Time (Max) | 3 ns |
| Fall Time (Max) | 3 ns |
| Operating Temperature (Max) | 105 ℃ |
| Operating Temperature (Min) | -40 ℃ |
| Power Dissipation (Max) | 240 mW |
| Supply Voltage | 3V ~ 5.5V |
| Supply Voltage (Max) | 5.5 V |
| Supply Voltage (Min) | 3 V |
| Show | |
| Size-Length | 5 mm |
| Size-Width | 4 mm |
| Operating Temperature | -40℃ ~ 105℃ |
| Product Lifecycle Status | Active |
| Packaging | Tube |
| RoHS | RoHS Compliant |
| Lead-Free Status | Lead Free |
| REACH SVHC Compliance | No SVHC |
| ECCN Code | EAR99 |
