- ADUM161N1BRZ - ADI
-
Manufacturer:ADI
-
ManyChip's Part#:MC568183
-
Category:Interface Isolator, Digital Isolator
-
Package:SOIC-16
-
Datasheet:Datasheet 3D Model
-
Description:ANALOG DEVICES ADUM161N1BRZ Digital Isolator, 3kV, 6Channel, 7.2ns, 1.7V, 5.5V, NSOIC, 16Pins New
-
Stock Locations:
-
Availability:247 pcs In Stock
-
MOQ:1 pcs
-
Unit Price:$ 2.43
Updated at 17/06/2025 10:30:15(UTC+8)
Certifications
ManyChip is committed to product quality and safety with ISO 9001, ISO 13485, ISO 45001, UL, RoHS, CQC and REACH certifications.
Description
- The ADUM161N1BRZ is a 3KV RMS, 6-channel digital isolator in 16 pin NSOIC package. This 6-channel digital isolator based on Analog Devices iCoupler technology. Combining high speed, CMOS and monolithic air core transformer technology, these isolation components provide outstanding performance characteristics superior to alternatives such as optocoupler devices and other integrated couplers. The maxi-mum propagation delay is 13ns with a pulse width distortion of less than 4.5ns at 5V operation. Channel to channel matching of propagation delay is tight at 4ns maximum. The data channels are independent and are available in a variety of configurations with a withstand voltage rating of 3KVrms. The devices operate with the supply voltage on either side ranging from 1.7V to 5.5V, providing compatibility with lower voltage systems as well as enabling voltage translation functionality across the isolation barrier. DC correctness is ensured in absence of input logic transitions.
- Number of inputs VDD1 side is 5, number of inputs VDD2 side is 1
- High common-mode transient immunity of 100kV/µs, high robustness to radiated and conducted noise
- Low propagation delay of 13ns maximum for 5V operation, 15ns maximum for 1.8V operation
- 150Mbps maximum guaranteed data rate
- UL recognition 3000Vrms for 1 minute per UL 1577
- VDE certificate of conformity, CQC certification per GB4943.1-2011
- Low dynamic power consumption
- 1.8V to 5V level translation
- Fail-safe high output state
- Operating temperature range from -40°C to +125°C
- ESD (electrostatic discharge) sensitive device.
ADUM161N1BRZ Specifications
| Attribute | Attribute Value |
|---|---|
| Datasheet | Datasheet |
| 3D Model | 3D Model |
| Mounting Style | Surface Mount |
| Number of Pins | 16 Pin |
| Case/Package | SOIC-16 |
| Rise/Fall Time | 2.5 ns |
| Number of Channels | 6 Channel |
| Power Dissipation | 1.64 W |
| Isolation Voltage | 3000 Vrms |
| Fall Time (Max) | 2.5 ns |
| Fall Time (Max) | 2.5 ns |
| Operating Temperature (Max) | 125 ℃ |
| Operating Temperature (Min) | -40 ℃ |
| Power Dissipation (Max) | 1640 mW |
| Supply Voltage | 1.7V ~ 5.5V |
| Supply Voltage (Max) | 5.5 V |
| Supply Voltage (Min) | 1.7 V |
| Show | |
| Operating Temperature | -40℃ ~ 125℃ |
| Product Lifecycle Status | Active |
| Packaging | Each |
| RoHS | RoHS Compliant |
| Lead-Free Status | Lead Free |
| REACH SVHC Compliance Edition | 2016/06/20 |
