Description

The ADUM4135BRWZ is a single-channel Gate Driver specifically optimized for driving insulated gate bipolar transistors (IGBTs). Analog Devices Inc., iCoupler® technology provides isolation between the input signal and the output gate drive. It includes a Miller clamp to provide robust IGBT turn-OFF with a single-rail supply when the gate voltage drops below 2V. Operation with unipolar or bipolar secondary supplies is possible with or without the Miller clamp operation. The Analog Devices chip scale transformers also provide isolated communication of control information between the high voltage and low voltage domains of the chip. Information on the status of the chip can be read back from dedicated outputs. Control of resetting the device after a fault on the secondary is performed on the primary side of the device. Integrated onto the ADuM4135 is a de-saturation detection circuit that provides protection against high voltage short-circuit IGBT operation.
Desaturation protection
Isolated desaturation fault reporting
Soft shutdown on fault
Isolated fault and ready functions
Output voltage range to 30V
Output and input under-voltage lockout
Creepage distance - 7.8mm minimum
20 Years lifetime for 600Vrms or 1092VDC working voltage
<1R Output power device resistance
55ns Typical low propagation delay

Show

ADUM4135BRWZ Specifications

Attribute	Attribute Value

Datasheet	Datasheet
3D Model	3D Model
Mounting Style	Surface Mount
Number of Pins	16 Pin
Case/Package	SOIC-16
Supply Voltage (DC)	2.30V (min)
Operating Voltage	12V ~ 30V
Rise/Fall Time	16 ns
Number of Outputs	2 Output
Number of Channels	1 Channel
Rise Time	22.9 ns
Isolation Voltage	5000 Vrms
Fall Time	22.9 ns
Operating Temperature (Max)	125 ℃
Operating Temperature (Min)	-40 ℃
Supply Voltage (Max)	30 V
Supply Voltage (Min)	2.3 V
	Show
Size-Length	10.5 mm
Size-Width	7.6 mm
Size-Height	2.35 mm
Operating Temperature	-40℃ ~ 125℃
Product Lifecycle Status	Active
Packaging	Each
RoHS	RoHS Compliant
Lead-Free Status	Contains Lead
REACH SVHC Compliance Edition	2015/12/17
ECCN Code	EAR99
