ADUM5010ARSZ - ADI
Manufacturer:
ADI
ManyChip's Part#:
MC120704
Category:
Interface Isolator, Digital Isolator
Package:
SSOP-20
Datasheet:
Datasheet 3D Model
Description:
ANALOG DEVICES ADUM5010ARSZ Digital Isolator, 1Channel, 3.3V, 5V, SSOP, 20Pins
Stock Locations:
Availability:
229 pcs In Stock
MOQ:
1 pcs
Unit Price:
$ 5.02

Updated at 17/06/2025 10:30:15(UTC+8)

Certifications

ManyChip is committed to product quality and safety with ISO 9001, ISO 13485, ISO 45001, UL, RoHS, CQC and REACH certifications.

Description

The ADUM5010ARSZ is an Integrated DC-to-DC Converter that provides regulated, isolated power, adjustable between 3.15V and 5.25V. Input supply voltages can range from slightly below the required output to significantly higher. The iCoupler chip-scale transformer technology is used for isolated logic signals and for the magnetic components of the DC-to-DC converter. The result is a small form factor, total isolation solution. isoPower uses high frequency switching elements to transfer power through its transformer. Special care must be taken during printed circuit board (PCB) layout to meet emissions standards.
isoPower integrated, isolated DC-to-DC converter
Up to 150mW output power
High temperature operation
High common-mode transient immunity (>25kV/µs)
ESD sensitive device, take proper precaution while handling the device.

Show

ADUM5010ARSZ Specifications

Attribute	Attribute Value

Datasheet	Datasheet
3D Model	3D Model
Mounting Style	Surface Mount
Number of Pins	20 Pin
Case/Package	SSOP-20
Supply Voltage (DC)	3.30V (min)
Power Rating	150 mW
Number of Outputs	1 Output
Output Voltage	5.25 V
Supply Current	30 mA
Number of Channels	1 Channel
Number of Positions	20 Position
Power Dissipation	2.5 W
Isolation Voltage	2.5 kV
Switching Frequency	125000 kHz
Input Voltage (Max)	5.5 V
Input Voltage (Min)	3 V
Output Voltage (Max)	5.25 V
Output Voltage (Min)	3.15 V
Output Current (Max)	30 mA
Input Power (Max)	150 W
Operating Temperature (Max)	105 ℃
Operating Temperature (Min)	-40 ℃
Power Dissipation (Max)	150 mW
Supply Voltage (Max)	5 V
Supply Voltage (Min)	3.3 V
Input Voltage	3.3V ~ 5.5V
	Show
Size-Length	7.5 mm
Size-Width	5.6 mm
Size-Height	1.85 mm
Operating Temperature	-40℃ ~ 105℃
Product Lifecycle Status	Active
Packaging	Tube
RoHS	RoHS Compliant
Lead-Free Status	Contains Lead
REACH SVHC Compliance	No SVHC
REACH SVHC Compliance Edition	2015/12/17
ECCN Code	EAR99
