ADUM7223ACCZ - ADI
Manufacturer:
ADI
ManyChip's Part#:
MC493167
Category:
Interface Isolator, Digital Isolator
Package:
LGA-13
Datasheet:
Datasheet 3D Model
Description:
ANALOG DEVICES ADUM7223ACCZ Digital Isolator, Dual, 2Channel, 40ns, 3V, 5.5V, LGA, 13Pins
Stock Locations:
Availability:
256 pcs In Stock
MOQ:
1 pcs
Unit Price:
$ 62.21

Updated at 01/11/2025 10:30:15(UTC+8)

Certifications

ManyChip is committed to product quality and safety with ISO 9001, ISO 13485, ISO 45001, UL, RoHS, CQC and REACH certifications.

Description

The ADUM7223ACCZ is an isolated half-bridge Gate Driver employs Analog Devices, Inc., iCoupler® technology to provide independent and isolated high-side and low-side outputs. Combining high speed CMOS and monolithic transformer technology, this isolation component provides outstanding performance characteristics superior to alternatives such as the combination of pulse transformers and non-isolated gate drivers. By integrating the isolator and driver in a single package, propagation delay is a maximum of only 64ns and the propagation skew from channel to channel is a maximum of only 12ns at 12V. It provides two independent isolation channels. It operates with an input supply ranging from 3 to 5.5V, providing compatibility with lower voltage systems. In comparison to gate drivers employing high voltage level translation methodologies, this gate driver offers the benefit of true, galvanic isolation between the input and each output.
565V Peak high-side or low-side relative to input
700V Peak high-side to low-side differential
1MHz Maximum high frequency operation
64ns Maximum propagation delay
8.5ns Maximum channel-to-channel matching
CMOS input logic levels
>25kV/µs High common-mode transient immunity

Show

ADUM7223ACCZ Specifications

Attribute	Attribute Value

Datasheet	Datasheet
3D Model	3D Model
Mounting Style	Surface Mount
Number of Pins	13 Pin
Case/Package	LGA-13
Supply Voltage (DC)	3.00V (min)
Rise/Fall Time	12 ns
Number of Outputs	2 Output
Output Current	2.3 mA
Supply Current	1.60 mA
Number of Channels	2 Channel
Number of Positions	13 Position
Rise Time	12 ns
Isolation Voltage	2500 Vrms
Fall Time	12 ns
Fall Time (Max)	24 ns
Fall Time (Max)	24 ns
Operating Temperature (Max)	125 ℃
Operating Temperature (Min)	-40 ℃
Supply Voltage	4.5V ~ 18V
Supply Voltage (Max)	5.5 V
Supply Voltage (Min)	3 V
	Show
Size-Length	5.1 mm
Size-Width	5.1 mm
Size-Height	1 mm
Operating Temperature	-40℃ ~ 125℃
Product Lifecycle Status	Active
Packaging	Tray
RoHS	RoHS Compliant
Lead-Free Status	Lead Free
REACH SVHC Compliance	No SVHC
REACH SVHC Compliance Edition	2015/12/17
ECCN Code	EAR99
