Attribute | Attribute Value |
---|---|
Datasheet | Datasheet |
3D Model | 3D Model |
Mounting Style | Through Hole |
Number of Pins | 4 Pin |
Case/Package | DIP-4 |
Voltage Rating (AC) | 250 V |
Current Rating | 0.059 A |
Insulation Resistance | 1000 MΩ |
Contacts Type | SPST-NO |
Power Consumption | 1400 mW |
Contact Current Rating | 31 A |
Coil Voltage | 24 VDC |
Coil Current | 58.6 mA |
Coil Resistance | 410 Ω |
Carry Current | 31.0 A |
Coil Voltage (DC) | 24 V |
Coil Power | 1.4 W |
Input Power (Max) | 7.75 KVA |
Switching Current (Max) | 31 a |
Operating Temperature (Max) | 60 ℃ |
Operating Temperature (Min) | -40 ℃ |
Voltage Rating | 24 V |
Show | |
Size-Length | 30.1 mm |
Size-Width | 15.7 mm |
Size-Height | 23.3 mm |
Contact Material | Silver Tin Oxide |
Operating Temperature | -40℃ ~ 60℃ |
Product Lifecycle Status | Active |
Packaging | Bulk |
RoHS | RoHS Compliant |
Lead-Free Status | Lead Free |
REACH SVHC Compliance | No SVHC |
REACH SVHC Compliance Edition | 2015/06/15 |
HTS Code | 8536490075 |
ECCN Code | EAR99 |
