Image is for your reference only,please check specifications for details

AMP01FX - ADI
Manufacturer:
ADI
ManyChip's Part#:
MC2554759
Category:
Amplifier, Buffer IC
Package:
CDIP-18
Datasheet:
Datasheet 3D Model
Description:
ANALOG DEVICES AMP01FX Instrument Amplifier, 1 Amplifier, 100µV, 4.5V/µs, 570kHz, ± 4.5V to ± 18V, DIP
Stock Locations:
Availability:
203 pcs In Stock
MOQ:
1 pcs
Unit Price:
$ 71.11

Updated at 17/06/2025 10:30:15(UTC+8)

Certifications

ManyChip is committed to product quality and safety with ISO 9001, ISO 13485, ISO 45001, UL, RoHS, CQC and REACH certifications.

Description

Product Details
The AMP01 is a monolithic instrumentation amplifier designed for high-precision data acquisition and instrumentation applications. The design combines the conventional features of an instrumentation amplifier with a high current output stage. The output remains stable with high capacitance loads (1 μF), a unique ability for an instrumentation amplifier. Consequently, the AMP01 can amplify low level signals for transmission through long cables without requiring an output buffer. The output stage can be configured as a voltage or current generator.
Input offset voltage is very low (20 μV), which generally eliminates the external null potentiometer. Temperature changes have minimal effect on offset; TCVIOS is typically 0.15 μV/°C. Excellent low frequency noise performance is achieved with a minimal compromise on input protection. The bias current is very low, less than 10 nA over the military temperature range. High common-mode rejection of 130 dB, 16-bit linearity at a gain of 1000, and 50 mA peak output current are achievable simultaneously. This combination takes the instrumentation amplifier one step further towards the ideal amplifier.
AC performance complements the superb dc specifications. The AMP01 slews at 4.5 V/μs into capacitive loads of up to 15 nF, settles in 50 μs to 0.01% at a gain of 1000, and boasts a healthy 26 MHz gain bandwidth product. These features make the AMP01 ideal for high speed data acquisition systems.
The gain is set by the ratio of two external resistors over a range of 0.1 to 10,000. A very low gain temperature coefficient of 10 ppm/°C is achievable over the whole gain range. Output voltage swing is guaranteed with three load resistances: 50 Ω, 500 Ω, and 2 kΩ. Loaded with 500 Ω, the output delivers ±13.0 V minimum. A thermal shutdown circuit prevents destruction of the output transistors during overload conditions.
The AMP01 can also be configured as a high performance operational amplifier. In many applications, the AMP01 can be used in place of op amp/power buffer combinations.
### Features and Benefits
Low offset voltage: 50 μV maximum
Very low offset voltage drift: 0.3 μV/°C maximum
Low noise: 0.12 μV p-p (0.1 Hz to 10 Hz)
Excellent output drive: ±10 V at ±50 mA
Capacitive load stability: up to 1 μF
Gain range: 0.1 to 10,000
Excellent linearity: 16-bit at G = 1000
High CMR: 125 dB minimum (G = 1000)
Low bias current: 4 nA maximum
Can be configured as a precision op amp
Output-stage thermal shutdown
Available in die form

Show

AMP01FX Specifications

Attribute	Attribute Value

Datasheet	Datasheet
3D Model	3D Model
Mounting Style	Through Hole
Number of Pins	18 Pin
Case/Package	CDIP-18
Operating Voltage	4.5V ~ 18V
Supply Current	3 mA
Number of Circuits	1 Circuit
Number of Channels	1 Channel
Number of Positions	18 Position
Common Mode Rejection Ratio	125 dB
Bandwidth	570 kHz
Slew Rate	4.50 V/μs
Input Offset Voltage	40 µV
Input Bias Current	2 nA
Operating Temperature (Max)	85 ℃
Operating Temperature (Min)	-25 ℃
3dB Bandwidth	570 kHz
Gain Bandwidth	75 dB
Minimum CMRR Range	75 dB
Supply Voltage (Max)	30V ~ 50V
	Show
Operating Temperature	-25℃ ~ 85℃
Product Lifecycle Status	Active
Packaging	Tube
RoHS	Non-Compliant
Lead-Free Status	Contains Lead
REACH SVHC Compliance Edition	2015/12/17
