Attribute | Attribute Value |
---|---|
Datasheet | Datasheet |
3D Model | 3D Model |
Mounting Style | Surface Mount |
Number of Pins | 16 Pin |
Case/Package | SOIC-8 |
Supply Current | 5 mA |
Number of Circuits | 1 Circuit |
Number of Channels | 1 Channel |
Common Mode Rejection Ratio | 110 dB |
Slew Rate | 6.00 V/μs |
Input Offset Voltage | 40 µV |
Input Bias Current | 4 nA |
Operating Temperature (Max) | 85 ℃ |
Operating Temperature (Min) | -40 ℃ |
3dB Bandwidth | 1.2 MHz |
Minimum CMRR Range | 75 dB |
Supply Voltage (Max) | 30V ~ 50V |
Supply Voltage (Min) | 4.5 V |
Show | |
Size-Length | 10.5 mm |
Size-Width | 7.6 mm |
Size-Height | 2.35 mm |
Operating Temperature | -40℃ ~ 85℃ |
Product Lifecycle Status | End of Life |
Packaging | Tube |
RoHS | Non-Compliant |
Lead-Free Status | Contains Lead |
