Attribute | Attribute Value |
---|---|
Datasheet | Datasheet |
3D Model | 3D Model |
Mounting Style | Through Hole |
Number of Pins | 7 Pin |
Case/Package | DIP-8 |
Frequency | 132 kHz |
Supply Voltage (DC) | 265V (max) |
Power Rating | 18 W |
Number of Outputs | 1 Output |
Output Voltage | 700 V |
Output Current | 880 mA |
Breakdown Voltage | 700 V |
Supply Current | 365 µA |
Number of Positions | 7 Position |
Output Power | 18 W |
Switching Frequency | 132 kHz |
Duty Cycle | 65 % |
Input Voltage (AC Max) | 265 v |
Input Voltage (AC Min) | 85 v |
Maximum Duty Cycle | 65 % |
Operating Temperature (Max) | 150 ℃ |
Operating Temperature (Min) | -40 ℃ |
Input Voltage | 85.265 V |
Show | |
Size-Length | 9.83 mm |
Size-Width | 6.6 mm |
Size-Height | 3.68 mm |
Operating Temperature | -40℃ ~ 150℃ |
Product Lifecycle Status | Active |
Packaging | Tube |
RoHS | RoHS Compliant |
Lead-Free Status | Lead Free |
REACH SVHC Compliance | No SVHC |
HK STC License | NLR |
