Attribute | Attribute Value |
---|---|
Datasheet | Datasheet |
3D Model | 3D Model |
Mounting Style | Through Hole |
Number of Pins | 8 Pin |
Case/Package | DIP-8 |
Frequency | 132 kHz |
Supply Voltage (DC) | 374V (max) |
Power Rating | 28 W |
Number of Outputs | 1 Output |
Output Voltage | 700 V |
Output Current | 2.16 A |
Breakdown Voltage | 700 V |
Supply Current | 1.60 mA |
Number of Positions | 8 Position |
Output Power | 20 W |
Switching Frequency | 132 kHz |
Duty Cycle | 66.5 % |
Input Voltage (AC Max) | 265 v |
Input Voltage (AC Min) | 85 v |
Maximum Duty Cycle | 83 % |
Operating Temperature (Max) | 150 ℃ |
Operating Temperature (Min) | -40 ℃ |
Input Voltage | 85.265 V |
Show | |
Operating Temperature | -40℃ ~ 150℃ |
Product Lifecycle Status | Active |
Packaging | Cut Tape (CT) |
RoHS | RoHS Compliant |
Lead-Free Status | Lead Free |
REACH SVHC Compliance | No SVHC |
REACH SVHC Compliance Edition | 2014/06/16 |
