Description

General Description
The AO6402A uses advanced trench technology to provide excellent RDS(ON) and low gate charge. This device is suitable for use as a load switch or in PWM applications. The source leads are separated to allow a Kelvin connection to the source, which may be used to bypass the source inductance.
Product Summary
VDS(V) = 30V
ID = 7.5A (VGS = 10V)
RDS(ON) < 24mΩ (VGS = 10V)
RDS(ON) < 35mΩ (VGS = 4.5V)

Show

AO6402A Specifications

Attribute	Attribute Value

Datasheet	Datasheet
3D Model	3D Model
Mounting Style	Surface Mount
Number of Pins	6 Pin
Case/Package	TSOP-6
Polarity	N-CH
Power Dissipation	2 W
Drain to Source Voltage (Vds)	30 V
Continuous Drain Current (Ids)	7.5A
Input Capacitance (Ciss)	820pF @15V(Vds)
Input Power (Max)	2 W
Power Dissipation (Max)	2W (Ta)
	Show
Operating Temperature	-55℃ ~ 150℃ (TJ)
Product Lifecycle Status	Active
Packaging	Tape & Reel (TR)
RoHS	RoHS Compliant
Lead-Free Status	Lead Free
