Attribute | Attribute Value |
---|---|
Datasheet | Datasheet |
3D Model | 3D Model |
Mounting Style | Through Hole |
Number of Pins | 8 Pin |
Case/Package | PDIP-8 |
Supply Voltage (DC) | 15.0 V |
Operating Voltage | 2.5V ~ 18V |
Supply Current | 4 mA |
Number of Circuits | 2 Circuit |
Number of Channels | 2 Channel |
Number of Positions | 8 Position |
Common Mode Rejection Ratio | 86 dB |
Input Offset Drift | 2.00 µV/K |
Bandwidth | 8 MHz |
Slew Rate | 20.0 V/μs |
Gain Bandwidth Product | 8 MHz |
Input Offset Voltage | 500 µV |
Input Bias Current | 5 pA |
Operating Temperature (Max) | 85 ℃ |
Operating Temperature (Min) | -40 ℃ |
Gain Bandwidth | 8 MHz |
Minimum CMRR Range | 86 dB |
Supply Voltage (Max) | 36 V |
Supply Voltage (Min) | 5 V |
Show | |
Size-Length | 9.81 mm |
Size-Width | 6.35 mm |
Size-Height | 4.57 mm |
Operating Temperature | -40℃ ~ 85℃ |
Product Lifecycle Status | Active |
Packaging | Tube |
RoHS | RoHS Compliant |
Lead-Free Status | Lead Free |
REACH SVHC Compliance | No SVHC |
