Attribute | Attribute Value |
---|---|
Datasheet | Datasheet |
3D Model | 3D Model |
Mounting Style | Through Hole |
Number of Pins | 5 Pin |
Case/Package | SIP |
Voltage Rating (AC) | 250 V |
Insulation Resistance | 1000 MΩ |
Contacts Type | SPDT |
Contact Current Rating | 6 A |
Coil Voltage | 24 VDC |
Coil Current | 7.1 mA |
Coil Resistance | 3.388 kΩ |
Current Rating (Max) | 6 A |
Coil Voltage (DC) | 24 V |
Coil Power | 170 mW |
Input Power (Max) | 1.5 KVA |
Switching Current (Max) | 6 A |
Operating Temperature (Max) | 85 ℃ |
Operating Temperature (Min) | -40 ℃ |
Show | |
Size-Length | 28 mm |
Size-Width | 5 mm |
Size-Height | 15 mm |
Contact Material | Silver Nickel |
Operating Temperature | -40℃ ~ 85℃ |
Product Lifecycle Status | Active |
Packaging | Tube |
RoHS | RoHS Compliant |
Lead-Free Status | Lead Free |
HTS Code | 8536490050 |
ECCN Code | EAR99 |
