Description

The AQW214A is a compact DIP 8-pin type MOSFET Relay with 400V controls load voltage. It is applicable for 2-form-A use as well as two independent 1-form-A uses. The PhotoMOS relay features extremely low closed-circuit offset voltage to enable control of low-level analogue signals without distortion. Fast operation speed of 310µs typical. The SSR has an OFF-state leakage current of several mA whereas the PhotoMOS relay has typical 100pA even with the rated load voltage of 400V. It eliminates the need for a counter electromotive force protection diode in the drive circuits on the input side.
High sensitivity, high speed response
Low-level OFF-state leakage current
Low-level thermal electromotive force
Stable ON resistance
Eliminates the need for a power supply to drive the power MOSFET
75mW Power dissipation
-40 to 85°C Operating temperature range

Show

AQW214A Specifications

Attribute	Attribute Value

Datasheet	Datasheet
3D Model	3D Model
Mounting Style	Surface Mount
Number of Pins	8 Pin
Case/Package	DIP-8
Supply Voltage (DC)	3.00 V
Voltage Rating (DC)	400 V
Current Rating	100 mA
Capacitance	0.8 pF
Output Voltage	0V ~ 400V
Output Current	100 mA
Contacts Type	DPST-NO
Load Current	100 mA
Input Current	50 mA
Power Dissipation	850 mW
Rise Time	310 µs
Isolation Voltage	1.5 kV
Forward Current	900 µA
Input Voltage (Max)	1.5 V
Output Voltage (Max)	400 V
Output Current (Max)	0.1 A
Input Current (Min)	50 mA
Operating Temperature (Max)	85 ℃
Operating Temperature (Min)	-40 ℃
Power Dissipation (Max)	850 mW
Input Voltage	1.14 VDC
	Show
Size-Length	9.86 mm
Size-Width	6.4 mm
Size-Height	2.9 mm
Product Lifecycle Status	Active
Packaging	Tube
RoHS	RoHS Compliant
Lead-Free Status	Lead Free
REACH SVHC Compliance	No SVHC
REACH SVHC Compliance Edition	2015/06/15
