- CD40109BNSR - TI
-
Manufacturer:TI
-
ManyChip's Part#:MC18206833
-
Category:Voltage Level Translator IC
-
Package:SOP-16
-
Datasheet:Datasheet 3D Model
-
Description:TEXAS INSTRUMENTS CD40109BNSR Voltage Level Translator, 4Input, 6.8mA, 180ns, 3V to 18V, SOP-16
-
Stock Locations:
-
Availability:242 pcs In Stock
-
MOQ:1 pcs
-
Unit Price:$ 0.51
Updated at 17/06/2025 10:30:15(UTC+8)
Certifications
ManyChip is committed to product quality and safety with ISO 9001, ISO 13485, ISO 45001, UL, RoHS, CQC and REACH certifications.
Description
- The CD40109BNSR is a quad CMOS low-to-high Voltage Level Shifter contains four low-to-high-voltage level-shifting circuits. Each circuit will shift a low-voltage digital-logic input signal (A, B, C, D) with logical 1=VCC and logical 0=VSS to a higher-voltage output signal (E, F, G, H) with logical 1=VDD and logical 0=VSS. The CD40109, unlike other low-to-high level-shifting circuits, does not require the presence of the high-voltage supply (VDD) before the application of either the low-voltage supply (VCC) or the input signals. There are no restrictions on the sequence of application of VDD, VCC or the input signals. In addition, with one exception there are no restrictions on the relative magnitudes of the supply voltages or input signals within the device maximum ratings, provided that the input signal swings between VSS and at least 0.7VCC, VCC may exceed VDD and input signals may exceed VCC and VDD.
- Up and down level-shifting capability
- Three-state outputs with separate enable controls
- Standardized, symmetrical output characteristics
- 100% Tested for quiescent current at 20V
- Green product and no Sb/Br
CD40109BNSR Specifications
| Attribute | Attribute Value |
|---|---|
| Datasheet | Datasheet |
| 3D Model | 3D Model |
| Mounting Style | Surface Mount |
| Number of Pins | 16 Pin |
| Case/Package | SOP-16 |
| Supply Voltage (DC) | 3.00V (min) |
| Output Current | 6.8 mA |
| Number of Circuits | 4 Circuit |
| Number of Channels | 4 Channel |
| Number of Positions | 16 Position |
| Number of Bits | 4 Bit |
| Propagation Delay Max (tpd) | 100 ns |
| Number of Inputs | 4 Input |
| Operating Temperature (Max) | 125 ℃ |
| Operating Temperature (Min) | -55 ℃ |
| Number of Output Channels | 1 Channel |
| Supply Voltage | 3V ~ 18V |
| Supply Voltage (Max) | 18 V |
| Supply Voltage (Min) | 3 V |
| Show | |
| Size-Length | 10.5 mm |
| Size-Width | 5.6 mm |
| Size-Height | 1.85 mm |
| Operating Temperature | -55℃ ~ 125℃ |
| Product Lifecycle Status | Active |
| Packaging | Tape & Reel (TR) |
| RoHS | RoHS Compliant |
| Lead-Free Status | Lead Free |
| REACH SVHC Compliance | No SVHC |
| REACH SVHC Compliance Edition | 2015/06/15 |
| ECCN Code | EAR99 |
