Attribute | Attribute Value |
---|---|
Datasheet | Datasheet |
3D Model | 3D Model |
Mounting Style | Through Hole |
Number of Pins | 18 Pin |
Case/Package | DIP-18 |
Voltage Rating (DC) | 50.0 V |
Current Rating | 500 mA |
Output Voltage | 50 V |
Output Current | 500 mA |
Number of Channels | 8 Channel |
Number of Positions | 18 Position |
Polarity | NPN |
Power Dissipation | 2.25 W |
Input Capacitance | 15.0 pF |
Breakdown Voltage (Collector to Emitter) | 50 V |
hFE Min | 1000 @350mA, 2V |
Input Power (Max) | 2.25 W |
DC Current Gain (hFE) | 1000 |
Operating Temperature (Max) | 85 ℃ |
Operating Temperature (Min) | -20 ℃ |
Power Dissipation (Max) | 2250 mW |
Supply Voltage | 5 V |
Input Voltage | 30 V |
Show | |
Size-Length | 23.24 mm |
Size-Width | 7.1 mm |
Size-Height | 3.93 mm |
Operating Temperature | -20℃ ~ 150℃ (TJ) |
Product Lifecycle Status | Active |
Packaging | Tube |
RoHS | RoHS Compliant |
Lead-Free Status | Lead Free |
REACH SVHC Compliance | No SVHC |
ECCN Code | EAR99 |
HK STC License | NLR |
